- 6 -
10. Flange Handle’s Principal Movements
- ON, OFF(RESET) movements must operate smoothly when Door is locked.
- Flange Handle movement has to be verified during ON, OFF operation by totally pushing the handle as ⓑ.
- Enclosure Door only opens when Flange Handle is in “OFF” status.
- Door Open is impossible when Handle is on “ON”. In case of being necessary its opening, you have to unblock Lock equipment with a screwdriver (—) and twisting
clockwise the Pin Release that is located next to Handle as ⓒ.
- Do not move Flange Handle to ON if electricity flows at the moment of turning it on. Electric shock may occur.
Installation Instruction
