Gladiator GEARTRACK CHANNEL - Trim Options; Interior Corner; Exterior Corner; End Cap

11
1. Interior Corner
3. End Cap
2. Exterior Corner
4. Windows, Doors, and Outlets
Trim Options
■ You may choose to apply trim to any exposed corners or edges. Below are some recommended congurations:
NOTE: The current trim options do not apply to masonry block or poured concrete wall installation.
■ Trim may also be applied around windows, doors, and outlets. Be sure to notch the trim as shown to ensure a snug t:
A
C
D
B
A. Top trim
B. Notch
C. Side trim
D. Bottom trim
