Glamox Aqua Signal NL90 User Manual

1 2 5
1 7
2 8
3 9
104
5
6
Input fuse for main power supply
Module label
Input fuse for spare power supply
Terminals for NMEA 0183 communication
Earth wire
Output for input module power supply
TS35 rail for mounting
Input/output terminals for alarms
DB9 connectors for main unit connection
RJ45 connector for input module connection
4 6 7 9 108
54321 6 7 128 9 10 11
1 7
82
93
104
5
6
Input fuse
Switches for manual operation of lamps
RJ45 connector - from previous module
Module label
RJ45 connector - to next module
Earth terminal
Power supply - from previous module
TS35 rail for mountingPower supply - to next module
Fuses for lights
11
12
Input terminals for lights connection
3
Link M1 for first/second module selection
(only for ITSL input modules)
Power supply module
Input module
5
