Tautening/loosening the brake cables:
1. To tauten or loosen a brake cable, you first need to loosen
the lock nut on the brake lever in question.
2. Then turn the adjusting nut to tauten the brake cable (distan-
ce between the brake shoes and brake disc is reduced), or
in the opposite direction to loosen it (distance between the
brake shoes and brake disc increases).
3. After you have tautened the brake cable, tighten the lock nut
again to fix the adjusting nut in place.
• The setting is correct if the brake shoes are a max.
1 mm distance from the brake disc.
