The Vintage gazebo is now
ready to add the roof and
curtains. First apply the roof
canopy (M) simply throw the
roof over the top section and
spread it out so that all the
corners are close to the roof
bars. The easiest way to
secure the roof is to pull the
canopy over using the
elasticated ends and secure
the mid sections first, always
making sure the canopy is
even across the roof leaving
the 4 corners until last. For
the curtains undo each
section (as they are all zipped
together and from the internal
(inside) one curtain fits every
corner across one leg so
when zipped it will all join up.
If you need help with assembly or missing parts please contact our customer care team on:
support@glendale-leisure.co.uk
Now make the spider roof
support frame part (16)
Connecting all the roof poles
ensuring the corner poles
Part 8 are positioned to
attach the frame into the
corner.
Simply slot these in and then
lift the poles onto the frame
Secure the frame with bolt H2
