G GLENSOUND ELECTRONICS LTD
Date 08/12/00 Information Sheet Number WP14-87 Issue Number 1
Page 1 of 1
G GLENSOUND ELECTRONICS LTD. 5&6 BROOKS PLACE, MAIDSTONE, KENT, ENGLAND.
IDC CONN 6
WIRING INFORMATION (GSOC26)
PIN No FUNCTION TYPE
1 0v
2 Left to Next Subrack Audio
3 Left from Previous Subrack Audio
4 0v
5 Right from Previous Subrack Audio
6 Right to Next Subrack Audio
7 Flash Sync Logic
8 0v
9 Left Selector Switch Interlock Logic
10 Right Selector Switch Interlock Logic
