G GLENSOUND ELECTRONICS LTD
Date 08/12/00 Information Sheet Number WP14-88 Issue Number 1
Page 1 of 1
G GLENSOUND ELECTRONICS LTD. 5&6 BROOKS PLACE, MAIDSTONE, KENT, ENGLAND.
IDC CONN 8
WIRING INFORMATION (GSOC26)
PIN No FUNCTION TYPE
1 No Connection
2 No Connection
3 Co-ord Pot Anti-clockwise Audio
4 Co-ord Pot Wiper Audio
5 0v
6 Feedback Pot Anti-clockwise Audio
7 Feedback Pot Wiper Audio
8 0v
9 4 Wire Pot Anti-clockwise Audio
10 4 Wire Pot Wiper Audio
11 0v
12 International Sound Pot Anti-clockwise Audio
13 International Sound Pot Wiper Audio
14 0v
15 Guide 1 Pot Anti-clockwise Audio
16 Guide 1 Pot Wiper Audio
17 0v
18 Guide 2 Pot Anti-clockwise Audio
19 Guide 2 Pot Wiper Audio
20 0v
