G GLENSOUND ELECTRONICS LTD
Date 08/12/00 Information Sheet Number WP14-90 Issue Number 1
Page 1 of 1
G GLENSOUND ELECTRONICS LTD. 5&6 BROOKS PLACE, MAIDSTONE, KENT, ENGLAND.
IDC CONN 13
WIRING INFORMATION (GSOC26)
PIN No FUNCTION TYPE
1 Mic B LED On Logic
2 Mic A LED On Logic
3 Mic C LED On Logic
4 Tape C Led On Logic
5 0v
6 Mix to Comms Box Audio
7 0v
8 No Connection
9 0v
10 No Connection
11 0v
12 No Connection
13 0v
14 PGM Out Audio
15 0v
16 Co-ord Out Audio
17 Ring Loop
18 Ring Loop
19 0v
20 Comm to Co-ord Audio
21 0v
22 C to Fader Audio
23 0v
24 B to Fader Audio
25 0v
26 A to Fader Audio
