G GLENSOUND ELECTRONICS LTD
Date 08/12/00 Information Sheet Number WP14-91 Issue Number 1
Page 1 of 1
G GLENSOUND ELECTRONICS LTD. 5&6 BROOKS PLACE, MAIDSTONE, KENT, ENGLAND.
IDC CONN 14
WIRING INFORMATION (GSOC26)
PIN No FUNCTION TYPE
1 0v Audio
2 Talkback @ -10 Audio
3 0v
4 0v
5 Comm Talkback Audio
6 4 Wire Talkback Audio
7 Short Circuit LED Drive Logic
8 Co-ord Talkback Audio
9 To Co-ord LED on Box Logic
10 Open Circuit LED Drive Logic
11 Comm Calls Home Logic
12 On Air LED Logic
13 Comm A Speak Logic
14 Comm Calls Technician Logic
15 Ring Comm Logic
16 Comm B Speak Logic
