G GLENSOUND ELECTRONICS LTD
Date 08/12/00 Information Sheet Number WP14-92 Issue Number 1
Page 1 of 1
G GLENSOUND ELECTRONICS LTD. 5&6 BROOKS PLACE, MAIDSTONE, KENT, ENGLAND.
IDC CONN 15
WIRING INFORMATION (GSOC26)
PIN No FUNCTION TYPE
1 Mix Monitor Audio
2 Feed to LED PPM Audio
3 Line Monitor Audio
4 0v
5 Co-ord Out Monitor Audio
6 Comm to Co-ord Monitor Audio
7 Co-ord In Monitor Audio
8 0v
9 Feedback Monitor Audio
10 0v
11 4 Wire Monitor Audio
12 0v
13 IS Monitor Audio
14 0v
15 Guide 1 Monitor Audio
16 0v
17 Guide 2 Monitor Audio
18 0v
19 Prefade B Monitor Audio
20 0v
21 Prefade A Monitor Audio
22 0v
23 Prefade C Monitor Audio
24 0v
25 Technician Speaks on PGM Logic
26 0v
27 -10 Talkback Audio
28 0v
29 Speak to Co-ord Logic
30 Send Co-ord Ident Logic
31 Send PGM Ident Logic
32 Technician calls Co-ord Logic
33 PGM Ident Audio
34 Co-ord Ident Audio
