7. Warranty & Repair
If your product develops a fault within 12 months from the date of purchase Global Laser will
repair / replace the product. If you wish to return a faulty product contact your local representative
or Global Laser to obtain a RMA (Return Material Authorisation code) and return to the address
below:
Global Laser Ltd
Units 9-10
Roseheyworth Business Park
Abertillery
Gwent, NP13 1SP
United Kingdom
If you require a longer line then a 80° fan angle will produce at the working distance then a pos-
sible solution may be to change the mounting position and angle of the laser, By moving the
laser to end of the working area and angling the laser to a 50° angle to the work surface the line
length is increased by a factor of 3. See the table below and the diagram for further detail.
Working Distance (mm) Line Length (mm)
250 2879
500 5759
1000 11517
2500 28749
Laser mounted
90° to surface
Laser mounted
50° to surface
5 Meter Line
0.5 Meters
2.5 Meters
