Global 670171 - Schematic; French; Schéma; Spanish

3
COMPACT DUAL FLOW 5-CHEMICAL DISPENSER
23
23
Schematic
Spares Diagram – ECOMIX COMPACT– Feb 2016 (Revision 1.3)
Part No.
Description
Qty
1
SBW8161
BSP WATER INLET VALVE
1
1
SBW8162
BSP WATER INLET VALVE
10
1
SBW8182
NPT WATER INLET VALVE
1
1
SBW8183
NPT WATER INLET VLAVE
10
2
SBW8184
BACKPLATE
1
3
SBW8185
COVER
1
4
SBW8165
DILUTION PIN ASSEMBLY
5
5
SBW8186
BRIGHT GAP LF VENTURI ASSEMBLY
1
5
SBW8187
BRIGHT GAP HF VENTURI PIN ASSEMBLY
1
6
SBW8188
AIR-GAP LF VENTURI ASSEMBLY
1
6
SBW8189
AIR-GAP LF VENTURI ASSEMBLY
1
7
SBW8150
JOINING PIECE
10
7
SBW8151
JOINING PIECE
50
8
SBW8152
JOINING PIECE FOR CABINET
1
9
SBW8153
BUCKET HOOK
5
10
SBW8154
SPRAY BOTTLE BRACKET
5
11
SBW8155
NON RETURN VALVE FOOT EPDM
10
11
SBW8176
NON RETURN VALVE FOOT VITON
10
11
SBW8177
NON RETURN VALVE FOOT EXTREME VITON
10
12
SBW8156
NON RETURN VALVE INLINE EPDM
10
12
SBW8178
NON RETURN VALVE INLINE VITON
10
12
SBW8179
NON RETURN VALVE INLINE EXTREME VITON
10
12
SBW8156
NON RETURN VALVE INLINE EPDM
10
13
SBW8159/?
DISPENSER COLOUR RING - Various colours
10
14
SBW8160/?
CABINETCOLOUR RING - various colours
10
15
SBW8191
B-GAP HF 1.5M PVC TUBE WITH FLOOD RING
5
16
SBW8190
B-GAP LF OUTLET TUBE WITH FLOOD RING
5
16
SBW8192
AIR-GAP LF PVC TUBE WITH FLOOD RING
5
15
SBW8193
AIR-GAP HF PVC TUBE WITH FLOOD RING
5
1
3
13
14
4
22
3
21
18
19
20
