INSTALLATION MANUAL
5.10.3 Placing the glass pane
Placing the glass pane will take place in reverse order of removing the glass pane, as described above.
!Caution
- Avoid/remove fingerprints on the glass pane, as they will burn into the glass;
- The self-tapping screws should not be over-tightened, since otherwise they could break or strip the thread:
tight = tight;
- Place the glass pane with the logo at the bottom right.
!Caution
Make sure the front glass pane fully connects with the side pane (there should be no opening between the side
and front pane).
If the front and side pane do not fully connect;
Ø
Loosen the self-tapping screws in the side pane's clamp strips by a few turns.
Ø
Slide the side pane tightly against the front pane.
!Caution
Make sure there is no sealing tape between the front and side pane (on the location where the two panes
connect).
Ø
Tighten the self-tapping screws of the clamp strips.
5.11 Setting the appliance
The appliance has to be set in such a way that it works correctly in combination with the used concentric system.
For that purpose, a restrictor slide is placed and/or the air inlet guide is removed. The conditions for using a wall
terminal and roof terminal can be found in appendix 2, tables 4, 5 and 6.
This appliance is suitable for PowerVent®. For more information, see the PowerVent® installation manual.
5.11.1 Restrictor slide (R)
The restrictor slide (R) is supplied separately. It is mounted as follows (see appendix 3, fig. 9):
Ø
Unscrew the 2 already placed self-tapping screws (U) from the combustion chamber.
Ø
Install the restrictor slide (R). It partly covers the hole of the exhaust pipe.
Ø
At the same time, tighten the 2 self-tapping screws (U) by a few turns, but not yet fully tight;
!Caution
When mounting, the arrow on the restrictor slide should point away from you (see appendix 3, fig. 9).
Ø
Adjust the position of the restrictor slide (R) using situations B to D in appendix 2, table 6. The letter of the position
on the restrictor slide corresponds with the letter of the situation in table 6;
Ø
Make sure that the point of the triangle belonging to the position that you want and the centre of the self-tapping
screw are exactly aligned;
Ø
Tighten the 2 self-tapping screws (U).
5.11.2 Air inlet guide (L)
The air inlet guide (L) is located at the back of the combustion chamber, under the plate (M).
If you want to remove it, proceed as follows (see appendix 3, fig. 10):
Ø
Unscrew the self-tapping screws from the plate (M) and remove the plate from the combustion chamber.
Ø
Loosen the 2 self-tapping screws (N) of the air inlet guide (L) and remove the air inlet guide;
!Caution
Then, re-tighten the 2 self-tapping screws (N) of the air inlet guide in the combustion chamber;
Ø
Place the plate (M) back in the combustion chamber.
