INSTALLATION MANUAL

5.12 Placing the wood or pebble set

The appliance is supplied with a wood set or a pebble set.

!Caution

Strictly observe the following instructions to prevent unsafe situations:

only ever use the supplied wood or pebble set;

place the wood and pebble set exactly as described;

make sure the pilot burner and the surrounding space remain free (see appendix 3, fig. 11);

make sure thermocouple 2 and the surrounding space remain free (see appendix 3, fig. 12.

In case of a wood set, keep the air openings between the burner and the vermiculite tray completely free.

5.12.1 Wood set

The wood set consists of chips (see appendix 3, fig. 13) and a number of logs.

Identify logs A to D using appendix 3, fig. 14.

!Tip

Use the burn stains on the logs for identification.

Place log A behind the (main) burner against the position bracket and distribute the chips (see appendix 3, fig. 15).

Place log B on the position bracket. Log B makes contact with both the protruding edge of the hood around the

pilot flame and log A (see appendix 3, fig. 16);

Place log C, it rests on log B.

Place log D on the position bracket. The point of log D makes contact with log A (see appendix 3, fig. 17);

!Caution

The logs should not completely cover the burner deck, because

- The main burner will not ignite properly; which could result in unsafe situations;

- Appliance will become filthy more quickly, as a result of soot;

- The flame picture will be affected.

If applicable and required, distribute the glow material over the burner(s).

!Caution

Fasten the glow material under chips and/or wood set.

5.12.2 Pebble set

The pebble set consists of white carrera pebbles.

Remove the 3 position brackets (P) by unscrewing the self-tapping screws (O). It is not necessary to place the

self-tapping screws back (see appendix 3, fig. 18);

Fill the burner and the vermiculite tray with carrera pebbles.

Spread the carrera pebbles evenly over one layer (see appendix 3, fig. 19).

!Caution

Incorrect placement of the pebbles, e.g. on top of each other, could have the following consequences:

- the main burner will not ignite properly, which could result in unsafe situations;

- the flame picture will be affected.
