Section 5 Operating Instructions
5-10
Figure 5-10 Fuse Replacement
Remove Cover
Op
en Fuse Compartment
Re
place with T
wo (2)
6
Amp 250V Fuses
Horizontal Fixed
Arm V
ersion
Remove Screw
Open Fuse
Compartment
Replace with
T
wo (2) 6
Amp
250V Fuses
Remove Cover
Remove 2 Screws
and Remove Cover
45° Arm
V
ersion
NOTICE
If your new fuse blows soon after installing it, you could have problems in that circuit. Contact
Global Surgical T
echnical Support for assistance.
30
32
