Glomex weBBoat 4G - INSTALLATION

weBBoat 4G
9
3.1 INSTALLATION
Installation on sailboats
It is advisable to place the weBBoat to a maximum height of 8/10 meters on
the shaft cross with the support Glomex code ITM001 (not supplied).
The weBBoat must be fixed to the support by tightening the screw on the
bottom of weBBoat with a screwdriver (Fig. 6).
IMPORTANT: Do not install the weBBoat masthead.
GL00153
NO
OK
8 - 10 m MAX
Fig. 5
WITH ITM001
(OPTIONAL)
WITH ITM001
(OPTIONAL)
GL00188
Fig. 6
