Glow-worm Climapro2 RF Installation

0020094586_01-08/10-Glow-worm
- 17 -
TECHNICALDATA

 


 



Transmission/reception
frequency
MHz 868
Transmission/reception
frequencybetweentheoutdoor
sensorandtheroomthermostat
min 15
Transmission/reception
frequencybetweenthe
applianceandtheroom
thermostat
min 10
Averageunobstructedworking
range(*)
m 100
Averagerangewithinthehome
(*)
m 25
(*)Canvaryaccordingtoinstallationconditionsandelectromagnetic
environment

Roomtemperatureauthorized
intheroomwherethecontrolis
installed
°C 50
Maximumauthorised
temperatureofdomesticwater
°C 65
Dimensions:
Height mm 173
Width mm 62,5
Depth mm 34
Supply:4“AALR6"alkaline
batteries
V 4x1.5
Batterylife(**) month 18
(**)Undernormalconditionsofuse

Dimensions:
Height mm 58
Width mm 66
Depth mm 27
Spacingbetweentheroom
thermostat(insupport)andthe
wall
mm 6
 
  
Transmission/reception
frequency
MHz 868
Transmission/reception
frequencybetweentheoutdoor
sensorandtheroomthermostat
min 15
Transmission/reception
frequencybetweenthe
applianceandtheroom
thermostat
min 10
Averageunobstructedworking
range(*)
m 100
Averagerangewithinthehome
(*)
m 25
(*)Canvaryaccordingtoinstallationconditionsandelectromagnetic
environment

Dimensions:
Height mm 20
Width mm 171
Depth mm 58
Power-supplyvoltageEBUS V 24V
Electricalconnectioncable
section
mm² 2x0.75
Max.lengthofelectric
connectioncables
m 300

Glow-worm Climapro2 RF Specifications

General

Display	LCD
Compatibility	Glow-worm boilers
Mounting	Wall-mounted
Range	Up to 30 meters
Type	Programmable thermostat
Programming	7-day programming
Power Source	Battery-powered
Communication	Radio Frequency (RF)
Features	Optimum start, Holiday mode, Frost protection
Battery Type	AA batteries
