0020096321_01 - 02/11 - Glow-worm
- 5 -
Key
1 Overheating safety (UFH shown, but can be underfl oor or radiators)
2 Hydraulic module
3 Heating circuit
4 Climapro2 RF programmable wireless room thermostat
5 Systempro control unit
6 Wireless outdoor sensor
7 Hydraulic module electrical supply + protection (This must have it's
own single isolation)
8 Heat pump electrical supply + protection (This must have it's own
single isolation)
9 EBus heat pump
10 Heat pump circuit fi lter (not supplied)
11 Glycol PRV discharge
A Heating circuit return
B Heating circuit fl ow
C Heat pump circuit safety valve discharge
D Heat pump circuit fl ow
E Heat pump circuit return
Application conditions
- The Systempro control unit manages the operation of the
boiler, the heat pump and the module.
- The Systempro control unit manages up to 3 heating zones.
- Each wireless room thermostat can control a heating zone.
- The installation can be performed with a low-temperature
heated fl oor (heating outlet temperature < 50°C) or low
temperature radiators (heating outlet temperature < 70°C).
- The overheating safety device must be connected to the
hydraulic module pump power supply.
e
Use 0.75 mm² section cables for the electrical
connections to the control unit.
Control unit settings
Description of main settings Setting
Diagram no. 4
Did you install a multizone kit ? No
Heating curves 0.1 - 1.5
Max. heating fl ow temperature 30°C < T < 70°C
INSTALLATION
