11 Spare Parts
11.1 Part Identification
The key number on the diagram and the list will help to identify
the part.
11.2 Ordering
When ordering any spare parts please quote the number and
description from the list together with the model name and serial
number.
If ordering from British Gas also quote the GC number of the
appliance and part.
Key No Part No Description GC Part No
1 203374 Multifunctional control *** ***
2 208040 “O” ring 334 592
3 203099 Injector - 30FF 313 389
4 203431 Pilot burner 379 204
5 2000801236 Mica window and foil gasket
6 2000800430 Fan assembly - 30FF 313 986
7 202626 Spark electrode and lead 313 998
8 K3580 Clip 390 983
9 800849 Thermostat - control - 30FF ******
10 202201 Air pressure switch 313992
11 2000800400 Control knob 313917
13 202015 Fuse 334750
14 900847 Control board (PCB) ******
15 800272 Thermostat cut-off 313 606
