Retaining screws
stored in cartridge
TANK / BOILER MODULE
CONNECTION W
ASHERS
N 3/4" Sealing Washer (blue) 4 OFF
M Cartridge Screws (stored in cartridge) 2 OFF
L Electrical Cartridge 1 OFF
K Floor Template 1 OFF
J Pump Washer 1 OFF
H 3/4" Sealing Washer (beige) 5 OFF
G 1/2" Sealing Washer 2 OFF
F 3/4" Sealing Washer (white plastic) 4 OFF
E 15mm Copper Tail 1 OFF
D 22mm Copper Tails 4 OFF
C Condensate Connection Pipe 1 OFF
B User Instructions (not illustrated) 1 OFF
A Installation booklet (not illustrated) 1 OFF
LOOSE ITEMS PACK
D
TANK / JIG
CONNECTION W
ASHERS
