GLP
German Light Products GmbH (Instruction version: 1.0) / from software version: 1.18/18/12/10/n 19
6 Technical Specifications
Power supply
Power consumption
350 VA (Watt)
Power Input
~100-240 V AC, 50-60 Hz (wide range input)
Fuse protection
Micro-fuse 5x20 mm, T5A
Operational Parameters
Max. Ambient
Temperature
5° - 45°C (integrated overheating switch)
Mounting Position
Any (see relevant chapter)
Lighting System - Additive Color mixing
LED Type
19 x Osram Ostar RGBW multi-chip
Lifetime
50,000 h
Wavelength optimized for maximum presentable color space
Optical System
Full RGBW / High efficient Collimator cluster
Shutter / Dimmer (8/16 Bit)
Strobe- Effect with variable speed between 1 - 10 flashes per second, Random-Strobe, Pulse-
Effects
Continuous Dimmer 0 - 100%
Zoom
7 to 50 degree continuous zoom
Optical Patterns
Several hundred pre-defined beam patterns with direct access and manipulation
DMX Control
Standard USITT DMX-512, 5 pin XLR; [+] = Pin 3 / [-] = Pin 2 / [Ground] = Pin 1 / Pin 4&5 N.C.
Die DMX- Addressing starts at the DMX channel [001].
Pan / Tilt (8/16 Bit)
Pan- movement 660° in min. 3,2 seconds (Position Feedback)
Tilt- movement 300° in min. 1,5 seconds (Position Feedback)
Weights and Measures
Width of the base
341 mm
Length of the base
145 mm
height (head vertical)
375 mm (incl. standing foot/tripod)
Weight (net)
8.0 kg
