GLP impression X4 - 1 Description of Device

GLP  German Light Products GmbH (Instruction version: 1.0) / from software version: 1.18/18/12/10/n 4
1 Description of Device
1. Moving head (actively and
passively cooled)
2. Arm with various cooling
vents
3. LCD-Display/Menu (data
entry)
4. Base with various
connectors and Camlock
mounting system
1
2
3
4
5
base side 1
6
base s id e 2
7
8
9
10
10
FUSE T4A
5. Power On/Off
6. DMX- Output (3 pole)
7. DMX- Input (3 pole)
8. Micro-fuse 5x20mm, T5A
9. Mains supply (Powercon)
10. 2x Safety eyes
