GLW EC 65 - Protective Cover and Power Connection

START-UP EC 65
12/09 9
4. Mounting the protective cover
• Insert the safety pin (1) in the bottom die and
push in the protective cover (2) until you can feel it
snap in.
! The power supply to the EC 65 will be
cut off if the protective cover is not fitted
or is not fitted properly.
5. Connecting / switching on the EC 65
 Connect the foot switch (1) to the foot switch
connection.
 Connect the mains plug (2) on the mains
connection and the shock-proof plug (3) to the
mains socket.
 Switch on the EC 65 at the mains switch (4)
(press I).
 lights up (5).
Figure 5 Mounting the protective cover
Figure 6 Connecting / switching on the EC 65
