START-UP EC 65
12/09 11
7. Adjusting the dies
The protective cover must be pulled
off, pull out the mains plug!
Switch off the EC 65 at the power switch (1) (press
0).
Pull out the mains plug (2).
Pull off the protective cover (3).
Check the centring of the dies, adjust if necessary
(4).
Tighten the screw (5).
Push on the protective cover (6) and tighten the
screw (7).
Figure 8 Adjusting the dies
