GLW EC 65 - Opening Distance Setting

START-UP EC 65
12/09 13
10. Set the optimum opening distance
Press the top button until all 4 LEDs light up. The maximum opening distance is set.
Perform crimping.
!
Changes in the setting only become effective after the next crimping process.
If the opening distance is too large press the bottom button (3 LEDs light up) and perform a new
crimping.
Repeat the process until the optimum opening distance is set.
