GMC AC30G - Know Your Product

AC40G
Know your product
1. Handle
2. Pressure switch cover
3. On/off switch
4. Tank pressure gauge
5. Regulating knob
6. Regulated outlet valve
7. Regulated outlet
pressure gauge
8. Safety valve
9. Non-return valve
10. Drain cock
11. Air tank
12. Wheel (x 2)
13. Safety shield
14. Oil filling cap
15. Air filter assembly
16. Oil level glass
17. Oil drain plug
(not shown)
18. Air tap
