GMC DB250SMS - Description of Symbols; Specifications

GB
3
Environmental Protection
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
local authority or retailer for recycling advice
Description of symbols
The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.
Read instruction Manual.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Double insulated for additional protection.
Conforms to relevant legislation and safety
standards.
Declaration Of Conformity
The Undersigned: Mr Philip Ellis as authorized by: GMC
Declare that:
PRODUCT CODE: DB250SMS/DB305SMS
DESCRIPTION: Double Bevel Slide Compound Mitre Saw
Electric power: 230-240V~ 50Hz 1800W
CONFORMS TO THE FOLLOWING DIRECTIVES:
• Directive 2004/108/EC Electromagnetic Compatability
• Directive 2006/95/EC Low Voltage Directive
• Directive 98/37/EC Machinery Directive
• Directive 2002/95/EC RoHS
• EN 61029-1: 2000+A11+A12, EN 61029-2-9: 2002
• EN 60825-1: 1994+A1+A2, EN 55014-1: 2000+A1+A2
• EN 55014-2: 1997+A1, EN 61000-3-2: 2006, EN 61000-3-11:2000
THE TECHNICAL DOCUMENTATION IS KEPT BY GMC
Date: 01/11/10
Signed by:
Mr Philip Ellis, Managing Director
Specifications
DB250SMS DB305SMS
Input power: 1800W 1800W
No load speed: 5000min
-1
5000min
-1
Blade size: Ø250mm Ø305mm
x Ø30mm bore x Ø30mm bore
Number of teeth: 24 30
Mitre table angles: 0° to 52° 0° to 52°
left & right left & right
Bevel cuts: 0° to 45° 0° to 45°
left & right left & right
Straight cut:
0° x 0°: 280mm x 80mm 305mm x 95mm
Mitre cut:
45° (L&R) x 0°: 196mm x 80mm 215mm x 95mm
52° (L&R) x 0°: 170mm x 80mm 186mm x 95mm
Bevel cut:
0° x 45° (R): 280mm x 27mm 305mm x 42mm
0° x 45° (L): 280mm x 52mm 305mm x 52mm
Compound mitre cut:
45° (R) x 45° (R): 196mm x 27mm 215mm x 42mm
52° (R) x 45° (R): 170mm x 27mm 186mm x 42mm
45° (L) x 45° (L): 196mm x 52mm 215mm x 52mm
52° (L) x 45° (L): 170mm x 52mm 186mm x 52mm
Weight: 25.7 kg 25.72kg
Noise and Vibration Data:
A Weighted Sound Pressure: 98dB(A)
A Weighted Sound Power: 111dB(A)
Uncertainty: 3dB(A)
Typical Weighted Vibration: 7.14m/s
2
Uncertainty: 1.5m/s
2
The sound intensity level for the operator may exceed
85dB(A) and sound protection measures are necessary
