1. Pulley cover
2. Belt tension lock knob
3. Head lock set screw
4. Feed handle x 3
5. Column
6. Column support
7. Column support bolts x 3
8. Base
9. Support lock
10. Table assembly
11. Chuck
12. Depth scale
13. Head assembly
14. ON/OFF Switch
15. Collar stop
16. Collar screw
17. Collar nut
18. Hex key
19. Feed wheel hub
20. Depth scale nut
21. Pulley cover knob
22. Quill
23. Chuck key
Know your product
Before using the drill press, familiarise
yourself with all the operating features
and safety requirements.
Use the tool only for the applications
intended. All other applications are expressly
ruled out.
