—Specifications—
1330-ED 1530-ED
HEIGHTS
Working Height* 19.1' 6m 20.7" 6.5m
Platform Height 13.1' 4 m 14.7" 4.5m
Stowed Height Rails Up 77" 1.95m 79.9" 2.03m
Rails Folded 59" 1.5m 62.6" 1.59m
Platform Floor 33.7" .86m 36.6" .93m
Guardrail Height 43.3" 1.1m 43.3" 1.1m
Toeboard Height 6" 15.5cm 6" 15.5m
DIMENSIONS
Length Stowed 56.2" 1.43m 66.8" 1.69m
With Step Removed 48" 1.22m 58.6" 1.49m
Width 29.9" .76m 29.9" .76m
Wheelbase 39.3" 1m 41.3" 1.05m
Ground Clearance 2" 5cm 6" 15cm
Platform Length, Stowed 48.4" 1.23m 50.4" 1.28m
Platform Width 29.3" .74m 29.9" .76m
Platform Length Extended 70.4" 1.79m 70.9" 1.8m
Platform Extension Deck Length 21.7" .55m 20.5" .52m
PERFORMANCE
Platform Lift Capacity 528lbs 240 kg 530 lbs 240 kg
Extension Deck Capacity 220 lbs 100 kg 220 lbs 100 kg
Turning Radius, Inside 14" 35cm 13.7" 35cm
Power Source 24v, 95Ah 24v, 95Ah
Drive System Direct Electric Drive Direct Electric Drive
Drive Speed Stowed 2 mph 3.2 km/h 2 mph 3.2 km/h
Elevated .5 mph .8 km/h .5 mph .8 km/h
Platform Lift Speed 21 23
Platform Lower Speed 18 19
Tires 9 x 3" 9 x 3"
Gradeability 30% 30%
Brakes Multiple disc Multiple disc
Weight, CE** 1609 lbs 730 kg 1895 lbs 860 kg
Weight, ANSI** 1609 lbs 730 kg 1895 lbs 860 kg
Drive Height Full Full
Meets applicable requirements of ANSI A92.6-2006. *Working Height adds 6 feet (2 m) to platform
height.
**Weight may increase with certain options.
