—Specifications—
3346-ED 4046-ED 4646-ED
HEIGHTS
Working Height* 39' 12m 45' 13.9m 51.8' 15.9m
Platform Height 32' 9" 10m 39.5' 11.89m 45.8' 13.9m
Stowed Height Rails Up 96" 2.44m 100.5" 2.55m 106" 2.69m
Rails Folded 69.4" 1.76m 74" 1.88m 78.7" 2m
Platform Floor 51.5" 1.31m 53" 1.34m 63" 1.6m
Guardrail Height 43.3" 1.1m 43.3" 1.1m 43.3" 1.1m
Toeboard Height 6.7" .17m 6.7" .17m 6.7" .17m
DIMENSIONS
Length Stowed 97" 2.46m 97" 2.46m 97" 2.46m
With Step Removed 91.5" 2.32m 91.5" 2.32m 91.5" 2.32m
Width 46" 1.17m 46" 1.17m 46" 1.17m
Wheelbase 72.8" 1.85m 72.8" 1.85m 72.8" 1.85m
Ground Clearance 4" 10cm 4" 10cm 4" 10cm
Pothole Bars Deployed .75" 1.9cm .75" 1.9cm .75" 1.9cm
Platform Length, Stowed 90.9" 2.31m 90.9" 2.31m 90.9" 2.31m
Platform Width 45.2" 1.15m 45.2" 1.15m 45.2" 1.15m
Platform Length Extended 130.7" 3.32m 130.7" 3.32m 130.7" 3.32m
Platform Extension Deck Length 39" 1m 39" 1m 39" 1m
PERFORMANCE
Platform Lift Capacity 771 lbs 350 kg 772 lbs 350 kg 507 lbs 230 kg
Extension Deck Capacity 265 lbs 120 kg 265 lbs 120 kg 253 lbs 115 kg
Turning Radius, Inside 0 0 0
Turning Radius, Outside 79" 2m 79" 2m 90.5" 2.3m
Power Source Direct Electric Drive Direct Electric Drive Direct Electric Drive
Drive System 24v, 225 Ah 24v, 225 Ah 24v, 225 Ah
Drive Speed Stowed 2.4 mph 3.8 km/h 2.4 mph 3.8 km/h 2.1 mph 3.4 km/h
Elevated .45 mph .7 km/h .45 mph .7 km/h .43 mph .7 km/h
Platform Lift Speed 50 65 97
Platform Lower Speed 38 50 46
Tires 16 x 5 16 x 5 16 x 5
Gradeability 25% 25% 25%
Brakes Multiple disc Multiple disc Multiple disc
Weight, CE** 6505 lbs 2950 kg 7110 lbs 3225 kg 7495 lbs 3400 kg
Weight, ANSI** 5505 lbs 2497 kg 5930 lbs 2690 kg 7231 lbs 3280 kg
Drive Height Full Full 32' 9" 10m
Meets applicable requirements of ANSI A92.6-2006. *Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
