GMG 1930-ED - Specifications

—Specifications—
1930-ED 2632-ED 2646-ED
HEIGHTS
Working Height* 25' 7.8m 32' 2" 10m 32' 2" 10m
Platform Height 19' 5.8m 26' 2" 8m 26' 2" 8m
Stowed Height Rails Up 85" 2.16m 90.5" 2.29m 88.5" 2.25m
Rails Folded 70.4" 1.79m 71" 1.8m 66.5" 1.69m
Platform Floor 40.5" 1.03m 46" 1.17m 46.5" 1.04m
Guardrail Height 43.3" 1.1m 43.3" 1.1m 43.3" 1.1m
Toeboard Height 6" 15.5cm 6" .15m 6" .15m
DIMENSIONS
Length Stowed 71.6" 1.82m 96.5" 2.45m 97" 2.46m
With Step Removed 65.3" 1.66m 89" 2.26m 91" 2.32m
Width 30" .76m 31.6" .80m 46" 1.17m
Wheelbase 52" 1.32m 73" 1.85m 72.8" 1.85m
Ground Clearance 2.1" 5.5cm 4" 10cm 4" 10cm
Pothole Bars Deployed .78" 2cm .7" 2cm .75" 1.9cm
Platform Length, Stowed 64.5" 1.64m 88.5" 2.25m 90.9" 2.31m
Platform Width 29.3" .74m 31.5" .8m 45.2" 1.15m
Platform Length Extended 99.8" 2.55m 127.5" 3.24m 130.7" 3.32m
Platform Extension Deck Length 36" .91m 39" 1m 39" 1m
PERFORMANCE
Platform Lift Capacity 507 lbs 230 kg 507 lbs 230 kg 992 lbs 450 kg
Extension Deck Capacity 253 lbs 115 kg 265 lbs 120 kg 265 lbs 120 kg
Turning Radius, Inside 0 0 0
Turning Radius, Outside 61.4" 1.56m 68.5" 1.74m 79" 2m
Power Source 24v, 224 Ah 24v, 225 Ah 24v, 225 Ah
Drive System Direct Electric Drive Direct Electric Drive Direct Electric Drive
Drive Speed Stowed 2.5 mph 4.02 km/h 2.5 mph 4.02 km/h 2.5 mph 4.02 km/h
Elevated .45 mph .7 km/h .45 mph .7 km/h .45 mph .7 km/h
Platform Lift Speed 22 28 39
Platform Lower Speed 15 29 34
Tires 14 x 4.5 14 x 4.5 16 x 5
Gradeability 30% 25% 25%
Brakes Multiple disc Multiple disc Multiple disc
Weight, CE** 3284 lbs 1490 kg 4409 lbs 2000 kg 5588 lbs 2535 kg
Weight, ANSI** 2700 lbs 1225 kg 4409 lbs 2000 kg 4530 lbs 2055 kg
Drive Height Full Full Full
Meets applicable requirements of ANSI A92.6-2006. *Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
