Technology for safety

D1000 series - Intrinsically Safe Isolators

Terminal blocks connection data

Stripping

lenght

Grey terminal blocks

on Safe Area

Screwdriver

for Trimmers

4 x 1 mm

7 mm

Connection data

Conductor cross section solid From 0.2 mm² to 2.5 mm²

Conductor cross section stranded From 0.2 mm² to 2.5 mm²

Conductor cross section stranded, with ferrule without plastic sleeve From 0.25 mm² to 2.5 mm²

Conductor cross section stranded, with ferrule with plastic sleeve From 0.25 mm² to 2.5 mm²

Conductor cross section AWG From 24 to 12 AWG

Blue terminal blocks

On Hazardous Area
