GNB DEC200 - Page 7

FIGURE 1: SINGLE PHASE INPUT
WARNING: IMPROPER WIRE AND JUMPER CONNECTION MAY CAUSE
SEVERE DAMAGE TO THE CHARGER AND BATTERY
NOTE: Live connection ‘L’ Must be connected to the breaker. The mains input are
the only user configurable connections. PCB connections must NOT be
altered from factory setting.
208 VAC 60Hz CONFIGURATION (208/240/480V INPUT)
240 VAC 60Hz CONFIGURATION (208/240/480V INPUT)
480 VAC 60Hz CONFIGURATION (208/240/480V INPUT)
Sales • Service • Recycling 1-888-563-6300
6
L
L
0
208
240
N
N
PCB
Mains Input
480
(Brown)
(Black)
(Black)
(Blue)
0
208
240
N
L
L
N
PCB
Mains Input
480
(Blue)
(Black)
(Black)
(Brown)
0
208
240
N
L
L
N
PCB
Mains Input
480
(Black)
(Brown)
(Black)
(Blue)
