Go Power! Modified Sine Wave Inverter
Owner’s Manual
Go Power! Modified Sine Wave Inverter
Owner’s Manual
5
4
3. Features
3.1 Front view – GP-175
a) AC outlet:
Outlet sockets available: North America
b) ON/ OFF switch:
Leave in the OFF position during installation.
c) Power:
Lights green when GP-175 inverter is on.
d) Fault:
Lights red when fault has occurred.
3.1 Rear view – GP-175
a) Ventilation port:
Do not obstruct, allow at least 1 inch for air flow.
b) DC input plug:
Plugs into any car lighter.
4. Installation
4.1 Where to install
The power inverter should be installed in a location that meets the following
requirements:
a) Dry - Do not allow water to drip or splash on the inverter.
b) Cool - Ambient air temperature should be between 0°C and 40°C (the cooler the
better).
c) Ventilated - Allow at least two inches of clearance around the inverter for airflow.
Ensure the ventilation openings on the rear and bottom of the unit are not obstructed.
d) Safe - Do not install the inverter in the same compartment as batteries or in any
compartment capable of igniting flammable liquids such as gasoline.
e) Inverter should be located within 10 feet of the batteries.
4.2 Hook-up and testing
* Important: The DC car lighter input cable includes a 15 Amp fuse. Most North
American car lighters are rated between 10 - 15 Amps DC and are fused in the
automobile fuse box.
a) AC outlet
c) Power
d) Fault
b) ON/ OFF switch
a) Ventilation port
b) DC input plug
