gpelectric.com | [page 7]
®
1. Locate a sunlit area, free from overhanging branches or obstructions.
2. Remove solar panel kit from carrying case.
3. Unclip the two latches on the side of the unit and fold the two panels outward. Extend the two support legs to their maximum length
and lock in position.
4. Place solar panel facing the sun.
Avoid any shading no matter how small. An object as small as a broomstick held across the solar module may
cause the power output to be reduced. Overcast days may also cut the power output of the module.
To obtain maximum output it is suggested that the panel’s direction be frequently adjusted to track the sun’s
movement throughout the day (southerly exposure).
Stabilize the panel by inserting a tent peg into the grommet hole at the base of each leg.
5. SET-UP
TYPE MODULE SIZE
(CLOSED)
MODULE SIZE
(OPENED)
NET
WEIGHT
MAX
POWER
MAX
POWER
VOLTAGE
MAX
POWER
CURRENT
Module (H) x (W) x (D) (H) x (W) x (D) lbs / kg W V A
100W
(2x50W)
21.1 x 23.8 x 1.8 in
536 x 604.5 x 45.7 mm
21.1 x 47.6 x 0.9 in
536 x 1209 x 23 mm
8.4 lbs / 3.8 kg 100 19.8 5.06
4. PANEL SPECIFICATIONS
3.3 ADDITIONAL ACCESSORIES SOLD SEPARATELY
Visit gpelectric.com for product details.
Use your existing trailer plug to
access your battery for charging.
Park your RV in the shade and place
your solar panel in the sun using this
extension cable.
GP-PSK-7PIN
7 Pin Trailer Plug Adapter
GP-PSK-X30
30’ Extension Cable
FEATURES AND ACCESSORIES
Note
Note
