5. Connect battery clamps to the positive (red, +) and negative (black, -) battery terminals. Ensure that the
connection is secure. Connect the battery clamp cable to the rest of the solar panel cable using the quick
connect cable.
Ensure the battery clamps do not come in contact with one another.
Do not let water come into contact with the controller.
Do not leave the DuraLite kit outside overnight or during inclement weather.
6. 30-AMP SOLAR CONTROLLER
6.1 SOLAR CONTROLLER SPECIFICATIONS
DESCRIPTION VALUE DIMENSIONS (H X W X D):
Nominal System Voltage 12 VDC
Dimensions (H x W x D):
178.5 × 105.5 × 48.3mm
7.02 x 4.15 x 1.90 in
Weight: 300g / 10.6 oz
Recommended Wire Gauge:
#8 AWG
Warranty: 5 years
• PWM Charging
• 4 Battery Charging proles
• 4 Stage Charging
• Displays Charging Current, Battery
Voltage and Battery State of Charge
• Reverse Polarity protected
• Temperature Compensated
• RoHS Compliant, environmentally
safe
• Accepts up to 3 DuraLite Kits (300
watts of solar at 12 volts)
Range of Battery Input Voltage 8 ~ 32 VDC
Rated Charge Current 30A
Charging Output DC Voltage Range 9 – 14.9 VDC
Max. PV Short Circuit Current 30A
Max. PV Open Circuit Voltage
50V
Operating Consumption
(Display backlight on)
15 mA
Operating Consumption
(Display backlight o󰀨)
6 mA
Charge Circuit Voltage Drop 0.21V
Battery Types Supported
Vented & Sealed Lead Acid (GEL, AGM, Flooded, etc.).
Lithium (LiFePO4)
Self-consumption ≤4.2mA/12V;≤2.6mA/24V
Temperature Compensation -3mV/°C/2V(Default)
Protection
Battery Reverse Polarity, PV Reverse Polarity, Over
Temperature, PV Short Circuit, PV Over Current, PV
Over Voltage,
This kit IS NOT
weatherproof
Never leave your Duralite Solar Kit unattended, plugged in
overnight, or subject to inclement weather.
6.2 SOLAR CONTROLLER WARNINGS
