gpelectric.com | [page 45]
OPERATION
4.7 BATTERY TEMPERATURE SENSOR (BTS) OPERATION
The IC Series Inverter/Charger is delivered with a battery temperature sensor. By installing this sensor, the charge voltages are
automatically adapted for deviating temperature. With a BTS installed, if the temperature around the BTS is below 20°C, the absorb and
oatchargevoltageincreases.IfthetemperaturearoundtheBTSisabove20°C,theabsorbandoatchargevoltagedecreases.The
graph below details how much the charge voltage changes (increases or decreases) depending on the temperature reading of the BTS.
4.8 FACTORY DEFAULT VALUES
The IC Series Inverter/Charger uses default values for the following adjustable settings:
Adjustable Settings Default Values
Shore Input 30 Amps (AC)
Low Battery Cut Out 10.5 VDC
VAC Dropout 85 VAC
Max Charge Time 12 Hours
Battery Type AGM 1
Charge Rate 80%
ABS Charge Time 2 Hours
These settings are only adjustable with the GP-ICR-50 remote, which can be purchased separately from Go Power!. For detailed
information on these settings please refer to the remote control manual. The remote also displays the real time Inverter/Charger’s
operatingstatusandallowstheusertoruntheequalizechargingproleonthebatterybank.
