3. APPEARANCE
NO. NAME NO. NAME
1-5 Instance Indicators 13 Connection Terminals (PV-)
6 LED Indicator (BAT2) 14 Connection Terminals (PV+)
7 LED Indicator (BAT1) 15 Port for external temperature sensor
8 LED Indicator (PV) 16 Canbus Communication Port
9 Connection Terminals (BAT2-) 17 RS485 Communication Port
10 Connection Terminals (BAT2+) 18 Setup Key
11 Connection Terminals (BAT1-) 19 Installation Hole
12 Connection Terminals (BAT1+)
