CHARGING INDICATOR LIGHT
Input Charge Indicator:
FLASHING BLUE - Power source is correctly plugged into
8mm input and charging.
BLUE - Lead-Acid battery is full.
Lead Acid State of Charge Indicator:
1 LED LIGHT - Lead-Acid battery is 25% full or less
2 LED LIGHTS - Lead-Acid battery is 25% - 50% full
3 LED LIGHTS - Lead-Acid battery is 50% - 75% full
ALL LED LIGHTS - Lead-Acid battery is 75% full or more
Error LED
FLASHING RED - Yeti is in an over voltage condition or lead
acid battery is in an under voltage condition. Disconnect
all Tank Cables from Link and Yeti and please call our solar
experts at 888-794-6250.
NOTE
1 The 8mm port on the Link is the only way to charge both the Yeti and
Tank. Input ports on the Yeti display will only charge the Yeti, not the Tank.
2 When Link and Tank are properly installed, power passes through the
8mm port to the Tank and then into the Yeti. Thus, without a Tank or third
party battery attached, you cannot charge the Yeti directly using the 8mm
port on the Link.
FREQUENTLY ASKED QUESTIONS
Q: I’m charging my Yeti and it is connected to one or more Tank batteries,
but my Tank batteries are not filling up. What should I do?
A: First, make sure you are using the input on your Link to charge your
system. This input is the only way to charge both your Tank(s) and Yeti
at the same time. If you are using the correct input and still having a
problem, try resetting by reinstalling your Link.
Q: I installed my Link into my Yeti, connected my batteries, and I’m not
showing a charge. What’s going on?
A: Upon initial installation, the Link needs time to identify which type of Yeti
you own in order to maximize performance. It can take up to 30 seconds
to start operating.
