Landing Gear
(H0375-S)
Flat Head Cap Screws M3x8mm
Flat Head Cap
Screws M3x8mm
(HC134-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Finishing
Washer M3
..... x3
..... x3
Finishing Washer M3
Socket Head Cap Screw M3x10mm
..... x5
Canopy
Positioners
(H0159-S)
Main Frame
(H0354-S)
Vertical ESC Support
(H0368-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Finishing
Washer M3
(H0007-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
..... x3
..... x1
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Finishing
Washer M2.5
(H0255-S)
Metrix Hex
Nylon Nut M2.5
(HC200-S)
H0370
..... x2
Socket Head Cap Screw M2.5x8mm
Finishing Washer M2.5
..... x2
Metrix Hex Nylon Nut M2.5
..... x2
Socket Head Cap
Screw M3x12mm
(HC062-S)
Socket Head Cap Screw M3x12mm
..... x2
Bottom Head Cap Screw M4x8mm
Bottom Head Cap
Screw M4x8mm
(HC098-S)
..... x4
Copyright © 2013 - SAB Heli Division - All rights reserved
Page 7
Chapter 4, Carbon Frame
To Next Page
