Operation
Using the Video Light
● There are three ways for power supply:
1. Power supplied by
DC adapter(15V/4A).
2. Power supplied by Li-ion
battery (Sony NP-F970/
F950/F930) (7.4V).
● Long press the ON/OFF Power Switch, the video light begins to giving out light.
● LCD panel shows the information.
3. Power supplied by power
bank with an USB cable
(5V/2A).
Note: The power of S30 is 30W when power supplied by 15V/4A DC adapter or 10W when power
supplied by li-ion battery (Sony NP-F970/F950/F930) or power bank (5V/2A).
Light Brightness Adjustment
● Turn the select dial to adjust the light brightness.
● The light brightness adjustable range is at 10%~100%.
Focal Length Adjustment
When turning the Select Dial for Focal Length
counterclockwise to the end, the lighting coverage is the
biggest; when turning the Select Dial for Focal Length
clockwise to the end, the lighting coverage is the smallest.
Direction Adjusting Bracket
• This bracket can be rotated up by 340°.
• If the bracket is not tight enough after repetitive rotation,
please use the included wrench to fix it.
Note: 1. The LED spotlight will auto power off once powered on if the portable charger's
current is lower than 2A.
2. Fan start temperature: Fan 1 will start if the temperature is over 40°C and fan 2 will
start if over 45°C.
3. The LED spotlight will auto power off if the temperature is over 70°C.
1. Light Body 2. Barndoor Set 3. 5-meter Power Cord 4. Wrench 5. Adapter
6. 50cm Cable 7. 180cm Cable 8. USB Cable 9. Lithium Battery Box 10. Portable Bag
Included Items
- 11 - - 12 -
