Code
n(Mode)
n+1
n+2
CCT
FX
Note
0-51 52-255
Operation
Mode
DMX*(100/255)
Integer
0-100% Brightness
DMX*(total light
effects/255)
For example: total light
effects 8，DMX=160,
light effects
No.=160*8/255=5
3. DMX Control Mode
In main interface, short press MENU button once
and turn the select dial to switch until the DMX
icon is displayed. Short press the SET button and
the icon will be blinking. Then, turn the select dial
to set the DMX channel from 1 to 512. Adjustment
in 10 values quickly or 1 value normally. Then,
short press the SET button to confirm and the
icon will stop blinking. Short press the MENU
button to return to main interface.
DMX Parameters:
DMX*(100/255)
Integer
0-100% Brightness
* Product design and specifications are subject to change without notice.
Technical Data
Maintenance
This product, except consumables e.g. battery, power cable and connect cable, is
supported with a one-year warranty.
Avoid sudden impacts and the product should be dedusted regularly.
Maintenance of the flash must be performed by our authorized maintenance
department which can provide original accessories.
Unauthorized service will void the warranty.
If the product had failures or was wetted, do not use it until it is repaired by
professionals.
Changes made to the specifications or designs may not be reflected in this
manual.
Silent LED Video Light
Power Supply
Output Power
Color Temperature
100% Illuminance(LUX)
(1m,darkroom) (≈)
CRI
TLCI
Brightness Range
Channel(CH)
Group (GR)
Beam Angle
Working Environment Temperature
Control Method
2.4G Wireless Transmission Distance(≈)
Dimension (≈)
New weight(≈)
S60
AC Power Supply 100~240V 50/60HZ 0.9A
V-port battery Standard voltage: 14.8V (optional)
60W
5600K±300K
Spot(Central Area) 3200
Flood(Central Area) 40000
≥96
≥97
0~100%
32 (1 to 32)
16 (A to F/ 0 to 9)
6°-55°
-10~40°C
Smartphone APP/2.4G wireless remote
control/DMX control
50m
Light body: 264*107*100mm
Controller: 268*113*64mm
Light body: 1.36kg
Controller: 0.94kg
- 21 - - 22 -
