1. Turn off the camera and mount the flash trigger
on camera hot shoe. Then, power on the flash
trigger and the camera.
2. Slide the screen of X3 down from the top to
display <Setting>, press <Setting> to enter C.Fn.
menu, then press <Wireless> to set CH and ID. Slide
the screen from the left to the right to return to the
main interface, on which you can set the flash
mode and output power level of groups.
1. Turn off the camera and mount the flash trigger
on camera hot shoe. Then, power on the flash
trigger and the camera.
2. Slide the screen of X3 down from the top to
display <Setting>, press <Setting> to enter C.Fn.
menu, then press <Wireless> to set CH and ID. Slide
the screen from the left to the right to return to the
main interface, on which you can set the flash
mode and output power level of groups.
3. Turn on the camera flash V1, press the wireless
setting button and < > and <RX> icon will be
displayed on the LCD panel. Press the < MENU >
Button to enter the C.Fn. menu, set its channel and
ID the same to the flash trigger.
Note: please refer to the relevant instruction manual when
setting the camera flashes of other models.
3.Connect the studio flash to power source and power it
on. Press the MODE/Wireless button to make the < >
displayed on the panel and enter 2.4GHz wireless mode.
Press and hold the <GR/CH> button to set the same
channel to the flash trigger, and press the < GR/CH >
button to set the same group to the flash trigger.
3. Power on the outdoor flash and press the wireless
setting button and the < > will be displayed on the
LCD panel. Long press the <GR/CH> button to set
the same channel to the flash trigger, and press the
< GR/CH> button to set the same group to the flash
trigger.
Note: please refer to the relevant instruction manual when
setting the outdoor flashes of other models.
