4. Tool Operation (Important tips before starting work)
Please charge the battery to 100% before rst use (according to the relevant
government regulations). Please ensure that charging does not stop below 50% of the
battery's capacity.
4.1 Instructions for presetting the blind rivet nut
The functions to be set in advance should be followed according to the specication
of the blind rivet nut, the thickness and the thickness of the work piece. Due to different
types and specications of blind rivet nuts that may be provided by different suppliers,
the installation performance will vary greatly. Therefore, pre-installation (sample
riveting) is required when the function is set (before ofcial riveting) (Fig. 1) We
recommend that you use GOEBEL brand blind rivet nuts for optimum processing.
(1) Screw the blind rivet nut manually by ½ turn according to the above illustration,
vertically and straight onto the mandrel! ➁ Press the blind rivet nut in the direction of
the arrow and the blind rivet nut is automatically spindled on. ➂ Press the trigger button
and the blind rivet nut is pulled ④ The test riveting process is completed, the mandrel
automatically spindles the blind rivet nut. Check the riveting process according to the
above illustration and check whether the riveting condition is satisfactory.
15 | English
(Fig. 1)
