12
Specifications
Item Specification
Compliance HDMI 1.3, HDCP 1.2
Transmission protocol HDbitT
Transmission distance Cat5e: 100m, Cat6: 120m
Resolution
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@50/60Hz
IR frequency 20KHz - 60KHz
HDMI connector Type A, 19-pin, Female
Power consumption TX: 3.5W; RX: 3W
Power supply 5VDC / 1A
Operating temperature 32 - 140 F (0 -60 C)
Dimensions 5.1" (L) x 1.73" (W) x 0.91" (H)
Weight TX: 0.45lbs; RX: 0.44lbs
