Golden Technologies Buzzaround XL Series - Armrest Width Adjustment; Flip-up Armrests; Armrest Angle Adjustment


19
V. OPERATION
SEATING
Figure 6. Armrest Width Adjustment Figure 7. Armrest Angle Adjustment
Armrest Width Adjustment
To adjust the armrest width:
1. Loosen the adjustment knobs at the rear of the seat. See figure 6.
2. Slide the armrests in or out to the desired width.
3. Tighten the adjustment knobs.
 Be sure adjustments knobs are securely tightened against the
inserted armrest tube. Do not overextend the armrest.
Flip-up Armrests
Pull up on the end of either armrest to flip it up for easy transfer on and off your Golden
Buzzaround XL™. See #1 on figure 7.
Armrest Angle
Loosen the locknut by turning it counter-clockwise.
To increase the armrest angle, turn the armrest angle screw counterclockwise.
To decrease the armrest angle, turn the armrest angle screw clockwise.
See #2 on figure 7.
1
2
Locknut
