4.4 DRIVING THE TRACTOR
Before starting out, check to make sure the brakes are good.
Lower the parking brake (n.6 fig.1).
Disengage the clutch by depressing pedal n.19 fig.1.
Select a speed range with the range selector (n.17 fig.1). Position (see fig.5):
RM = Reverse
R = Creep
V = Fast
Engage the gear you want with the gear lever (n.16 fig.1). Position:
1-4 gives you 1st or 4th gear or 1st reverse depending on the range lever
position.
2-5 gives you 2nd or 5th gear or 2nd reverse depending on range lever position.
3-6 gives you 3rd or 6th gear or 3rd reverse depending on range lever position.
SELECTING GEARS
Gear 1st 2nd 3rd 4th 5th 6th
1st
REV
2nd
REV
3rd
REV
SPEED RANGE LEVER R R R V V V RM RM RM
GEAR LEVER 1-4 2-5 3-6 1-4 2-5 3-6 1-4 2-5 3-6
SPEED CHART
In kph - with engine at 3000 Rpm
(Speeds are purely indicative)
Range Creep Fast Reverse
Gear
Wheels
1st 2nd 3rd 4th 5th 6th 1st 2nd 3rd
5.00x15" 1,1 2,3 3,5 5,0 10,8 16,5 0,8 1.7 2,6
6.5/80x15" 1,1 2,4 3,6 5,2 11,2 17,0 0,8 1,7 2,6
6.00x16" (1) 1,2 2,6 3,9 5,6 12,0 18,4 0,9 1,9 2,9
(1) With mechanical steering for the countries where it is homologated.
Do not ride the clutch as this will cause rapid wear on the thrust bearing.
