7. TECHNICAL DATA
FLUE SYSTEM GPG30 Air Inlet 740mm x 25 mm
Flue Gas outlet 740mm x 25 mm
Flue Gas Inlet 740mm x 200mm
GPG-45 Air Inlet 1100mm x 25mm
Flue gas outlet 1100mm x 25mm
Flue gas outlet 1100mm x 25mm
MODEL WIDTH (MM) DEPTH (MM) HEIGHT (MM)
GPG-30 745 690 445
GPG-45 1130 690 445
SIDE VIEW
GPG-45 or AGPG/S-45
690
FRONT VIEW
GPG-30
GPG MODELS
GPG-45 or AGPG/S-45
1120
GPG-30
740
690
55
1015
915
685
IM027B2/p11
