7. TECHNICAL DATA
INJECTOR SIZES
Conversion to other gases
GPGD24,36,48 GPG
GPGDSA24-36,60 GPGDB12
Inner Outer
N.G 2.05 2.1 1.6 1.1 2.15
L.P. 1.3 1.3 1.0 0.7 1.25
CONVERSION INSTRUCTIONS
To convert from N.G. to L.P. gas do the following:
1. Replace N.G. burner injectors with L.P. injectors (refer to table on following
page).
2 Replace pilot injectors to required size.
N.G. #32
L.P. #22
3. Disconnect regulator from gas supply line & reconnect LP Regulator.
4. Reset pressure test point on manifold to 2.60 kPa.
5. Adjust burner aeration slide.
IM027B2/p10
