2. INSTALLATION
RECEIVING INSPECTION – PRE-INSTALLATION
• Please follow these instructions carefully.
• Remove cartons from unit and check for any damages.
• Report any damages to the transport company or your dealer.
• Lift off base and screw the adjustable legs on the unit,
• Set unit into correct position.
• Adjust feet till they are touching the floor and using a spirit level, level from left to
right.
• Also adjust front to back with a fall of about 2-3mm to the front to help fluing of the
unit.
• This operation is important as variation of 25mm to 76mm in a floor level is found to
be common.
• Make sure unit is under an exhaust hood that provides adequate ventilation.
• Check date plate to ensure appliance is suitable to the gas that it is being connected
to.
• The Rating Plate is located on the front bottom left side and has what the unit is set
up for as factory set and tested.
• Check all loose items listed on the back of the Warranty Card.
• Have your electrician connect a power point as per Electrical Authority and Local
Laws.
• Note: The appliance must be installed by an Authorised person and in accordance
with the regulations of the local Gas Authority AS5601/AG601 and any other
authority having jurisdiction
The appliance has been tested and preset before leaving our Factory, but small
adjustments may be necessary to suit pressure supply.
Correct operation of the appliance must be tested as part of the installation
procedure.
1. Have a licensed gas fitter or your Gas Company connect the appliance to the
gas supply, Location of the connection is on the left side 381mm from the rear
and approximately 114mm from the floor. The fitting is 19mm BSP. The
appliance must be installed in accordance with the rules of any authority
having jurisdiction.
2. The pressure regulator (NG) and LPG standards (AS4563/AG300 1.1.05) are
supplied as a loose item and a hand stop tap must be supplied as close to the
appliance as possible to stop and pressure drop.
IM036B2/4
